Install Whelen CSP & Strobes N' More Pro Series Switch
The Whelen CSP and Strobes N' More Pro Series Switch are designed to provide reliable control over strobe lighting systems in emergency and utility vehicles. This guide outlines the installation process to ensure optimal performance and safety.
1. Safety Precautions
Before beginning the installation:
-
Disconnect Power: Ensure the vehicle's battery is disconnected to prevent electrical hazards.
-
Review Manuals: Familiarize yourself with the installation manuals for both the Whelen CSP power supply and the Pro Series Switch.
2. Mounting the Switch
-
Select Location: Choose a convenient and accessible location on the vehicle's dashboard or console for mounting the switch.
-
Secure the Switch: Use the provided hardware to mount the switch securely, ensuring it does not obstruct any vehicle controls or displays.
3. Wiring Connections
-
Power Supply Connection:
-
Red Wire: Connect to a fused 12V positive power source.
-
Black Wire: Connect to a solid ground point on the vehicle chassis.
-
Control Wires:
-
Switch 1 (Yellow Wire): Controls strobe outlets 1 & 2.
-
Switch 2 (Green Wire): Controls strobe outlets 3 through 6.
-
Switch 3 (Blue Wire): Used for flash pattern selection.
-
Switch 4 (Violet Wire): Optional; used for high/low power mode selection.
-
Fuse Protection: Ensure all power connections are fused appropriately to protect against electrical surges.
4. Testing the Installation
-
Reconnect Power: Reconnect the vehicle's battery.
-
Function Test: Activate each switch to verify the corresponding strobe lights operate correctly.
-
Flash Pattern Selection: Use Switch 3 to cycle through available flash patterns.
-
High/Low Power Mode: If connected, use Switch 4 to toggle between high and low power modes.
5. Finalizing Installation
-
Secure Wiring: Ensure all wiring is neatly routed and secured to prevent movement or damage.
- Reinstall Panels: Reattach any vehicle panels or components removed during installation.
